Applications
Replacement Wattage
Dimension
Weight
Ambient Temperature Range
Voltage
Power Consumption(W)
Power Factor
Luminous Intensity (lm)
Luminous Efficiency (lm/W)
Correlated Color Temperature (CCT)
Weather Protection (IP)

TB50WX

Indoor Lowbay
100W T8 Fluorescent
L 48.03in x W 3.54in X D 1.97in
8.82 lbs
-45C to 55C
100~300Vac 50~60Hz
51
.99
5,100
100
3000K, 5000K and 6500K
IP52

TB100WX

Indoor Lowbay
200W T8 Fluorescent
L 48.03in x W 3.54in X D 1.97in
8.82 lbs
-45C to 55C
100~300Vac 50~60Hz
102
.99
10,200
100
3000K, 5000K and 6500K
IP52

---
